Description
| Image Sensor | 1/2.7″ 2MP PS CMOS Image Sensor (0.9407 cm) |
| Effective Pixels | 1920 (H) × 1080 (V) |
| Minimum Illumination | 0.001 lux@F1.4 (Color, 30 IRE), 0.001 lux@F1.4 (B/W, 30 IRE), 0 lux (IR on) |
| Angle Adjustment | Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360° |
| Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| RAM | 128 MB |
| ROM | 128 MB |
| White Balance | Auto, Natural, Street lamp, Outdoor, Manual, Regional custom |
| Gain Control (AGC) | Auto/Manual |
| Lens Type | Fixed-focal |
| Max. Aperture | F1.4 |
| Lens Mount | M12 |
| Close Focus Distance | 3.6 mm: 1.1 m |
| DORI Distance (3.6mm lens) | Detect: 53.8 m, Observe: 21.5 m, Recognize: 10.8 m, Identify: 5.4 m |
| Lens | 3.6 mm fixed Lens |
| S/N Ratio | >56 dB |
| Back Light Compensation | BLC / HLC / DWDR |
| Video Compression | Instastream, H.265, H.264, H.264H, H.264B, MJPEG (sub stream only) |
| Angle of View (3.6mm) | H: 86°, V: 46°, D: 103° |
| IR Number | 2 IR LED, 2 Warm light |
| IR Range | 30 meters |
| Warm Light Range | 30 meters |
| IR Control | Auto, Manual |
| Smart Illumination | Support |
| Stream Capability | Triple stream |
| Frame Rate | Main stream: 2MP (1920×1080), 1.3MP (1280×960), 720p (1280×720) @ 25/30fps Sub stream 1: 720p/D1/VGA/CIF @ 25/30fps Sub stream 2: D1/VGA/CIF @ 25/30fps |
| Resolution | 2MP (1920×1080), 1.3MP (1280×960), 720p (1280×720), D1 (704×576 / 704×480), VGA (640×480), CIF (352×288 / 352×240) |
| Noise Reduction | 3D NR |
| Iris Control | Fixed |
| Privacy Mask | 8 areas |
| ROI | Support (8 areas) |
| Audio | Built-in Mic |
| Audio Compression | G.711a, G.711Mu, PCM, G.726, AAC |
| OSD | Camera title, Date & Time |
| Bit Rate Control | CBR / VBR |
| Bit Rate | H.265: 3 kbps–6144 kbps, H.264: 8 kbps–6144 kbps |
| Protocol | SFTP, IPv6, IPv4, DNS, RTCP, NTP, RTP, HTTP, HTTPS, SNMPv3, TLS 1.2, TCP/IP, PPPoE, NFS, UDP, ICMP, IGMP, SSL, DHCP, SMTP, RTSPS, ONVIF (Profile S, G, T), unicast, multicast |
| Day/Night | Auto(ICR) / Color / B/W |
| SMD | Supports classification and detection of humans and vehicles |
| Mirror Function | Support |
| Ethernet | RJ-45 (10/100 Base-T) |
| SDK and API | Support |
| Browser Support | IE, Chrome, Firefox |
| Smart IR | Support |
| User/Host | 6 users (Total bandwidth: 48 Mbps) |
| Image Rotation | 0° / 90° / 180° / 270° (90°/270° supported at 2MP or lower) |
| Certificates | ISO 9001:2015, ISO 20000-1:2018, CE, FCC, RoHS, BIS, STQC |
| Power Source | 12 VDC / PoE (802.3at) |
| Power Consumption | Basic: 1.9 W (12 VDC), 2.4 W (PoE) Max: 11.5 W (12 VDC), 13.1 W (PoE) with full features on |
| Weatherproof Standard | IP67 |
