Description
| Spatial Resolution | 50% 1.0 LP/mm |
| Pixel Resolution | > 10 pixels/mm |
| Image Margins (Left & Right) | >= 0.6x iris radius |
| Image Margins (Top & Bottom) | >= 0.2x iris radius |
| Imaging Wavelength | 700-900 nm |
| Pixel Depth | 8 bits/pixel |
| Output Image | KIND1 to KIND7 with JPEG2000 compression |
| Capture Mode | Auto capture with built-in quality check |
| Capture Time | < 2 Sec |
| Safety Exempt Group | Per IEC 62471:2006-07 |
| ESD Air Discharge | 8 KV, contact type ±4 KV |
| Radiated Emission | FCC part 15B / IEC: CISPR 22 CLASS B standard |
| Radiated Immunity | As per IEC/EN 61000-4-3:2006 + A2:2010 |
| Health Safety | RoHS Compliant |
| Connectivity | USB 2.0 / USB 1.1 |
| Operating System Support | Windows XP, Windows 7, Windows 2008, Android, Linux, Embedded Linux |
