| Image Sensor |
1/2.8″ CMOS |
| Pixel |
4 MP |
| Max. Resolution |
2560 (H) X 1440 (V) |
| Electronic Shutter |
1/3s–1/30,000s |
| Min. Illumination |
Color: 0.05 lux@F1.6, B/W: 0.005 lux@F1.6, 0 lux@F1.6 (Illuminator on) |
| Illumination Distance |
20m – 30m (IR), 20m – 30m (white light) |
| Illuminator On/Off Control |
Manual; Smart IR |
| Illuminator Number |
4 (IR, White light) |
| PIR Sensor |
Yes |
| Lens Focal Length |
4mm |
| Max. Aperture |
F1.6 |
| Field of View |
H: 84°, V: 42°, D: 101° |
| Network |
4G |
| Frequency Band |
LTE-FDD: B1/3/5/7/8/20/28, LTE-TDD: Band 38/40/41, WCDMA: Band 1/5/8, GSM: 850/900/1800 Mhz |
| Storage |
Micro SD card (Support up to 256G) |
| Mobile View |
iOS; Android |
| Management Software |
Yes |
| PTZ |
Pan/Tilt Range: Horizontal direction: 350°; Vertical direction: 150° |
| Manual Control Speed |
Pan: 62°/s; Tilt: 36.3°/s |
| Video Compression |
H.265; H.264; H.264+; H.265+ |
| Resolution |
Main Stream (2560 X 1440), Sub Stream(640 X 360) |
| Video Frame Rate |
15fps |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 32 kbps–8192 kbps |
| Day/Night |
Auto (ICR) |
| BLC |
Yes |
| WDR |
DWDR |
| HLC |
Yes |
| Noise Reduction |
Yes |
| Motion Detection |
Yes |
| Motion Detection Area Setting |
Yes |
| Image Rotation |
Flip Image |
| Image Enhancement |
3D DNR |
| Audio Format |
AAC, G.711 |
| Solar |
Maximum Power: 5.5 W |
| Operating Temperature |
–40 °C to +80 °C (–40 °F to +176 °F) |
| Battery |
18000mAH Lithium-ion |
| Battery Status in App |
Yes |
| Max. Charging Voltage |
4.2 V |
| Battery Voltage |
3.6 V |
| Cycle Lifetime |
Sleep Mode: 7 days (1-hour remote live view per day) |
| Battery Life |
Sleep Mode: 7 days (1-hour remote live view per day) |
| Power Supply |
Type-C 5V/1A |
| Power Consumption |
Sleep: 35 mW, Static: 2.3 W (daytime, only SD storage), 2.5 W (daytime: pulling stream in 4G), 4.8 W (illuminator on, pulling stream in 4G), Max: 10 W (Illuminator + PTZ + Heater + Pulling Stream in 4G) White light warning |
| Motion |
Light Warning: Flash duration: 5s – 10s, Sound Warning: Yes, Sensitivity: Low / Medium / High |
| Warmlight |
Triggered by human movement |
| Siren |
Triggered by human movement |
| Event Alert Notification |
Optional Battery Life / Surveillance / Uninterrupted Recording |
| Recording |
If Battery status >80%, it records continuously. If Battery status <50%, it records only event. |
| Cloud Recording |
Yes |
| Environment |
Operating Temperature: 0 °C to +50 °C (32 °F to +122 °F), Operating Humidity: ≤ 95%, Storage Temperature: 0 °C to +50 °C (32 °F to +122 °F), Storage Humidity: ≤ 95% |
| Protection |
IP66 Water Proof, Lightning protection, Anti-surge |
| Port |
SIM Card: Yes, SD Card: Yes, Type C Port: Yes, Reset Button: Yes |
