Description
| Specifications | |
|---|---|
| Network Port | 4 10/100Mbps PoE RJ45 port (Port 1 – Port 4), 2 10/100Mbps RJ45 port uplink (Port 5 – Port 6) |
| Transfer Rate | 100Mbps Full Duplex, 10 or 100Mbps Half Duplex |
| Network Protocol | IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at |
| Performance | Bandwidth: 1.2Gbps (no block) Network delay (100 to 100Mbps): Maximum 20 ps (using 64 byte packet) Frame filtering and transmission rate: 10M port maximum 14,800pps, 100M port maximum 148,800pps |
| LED Indicator | Power, LINK/ACT, RESV, POE Indicator light |
| PoE Pin | 1/2+, 3/6- |
| Power | Max power for single port 30W, Internal power adapter: 60W |
| Environment | Operating Temperature: 0°-40°C Operating Humidity: 10%-90%, Non-condensing |
| Safety Regulations | CE/ROHS/FCC/CCC |
